How to Configure Centralized Logging with Journald and Rsyslog

Linux systems generate a steady stream of authentication, service, kernel, and application logs. On most systems, those logs never leave the machine that created them. If you're responsible for ten or twenty servers, that means checking each one separately. If one disappears before you can investigate it, its logs may disappear with it.

Centralized logging solves that by sending log messages to another server as they're created. Instead of searching every machine, you have one place to review activity across your environment.

This tutorial uses journald and rsyslog to build that setup.

Before You Begin

To follow this tutorial, you need:

• One Linux system to act as the central rsyslog server
• At least one Linux client that will forward logs
• Root or sudo access on each system
• rsyslog installed on the server and clients
• Network connectivity between the systems
• TCP port 514 allowed through the server firewall

The commands in this guide use TCP because it provides more reliable delivery than UDP. File locations and firewall commands may vary between Linux distributions.

What Is Centralized Log Management in Linux?

Centralized log management collects logs from multiple Linux systems and stores them on a central server instead of leaving them scattered across individual machines.

If all you have is one server, local logs usually aren't a problem. Open journalctl or check the files under /var/log, and you're looking at everything that machine recorded.

The workflow changes once more systems are involved. An application error on one server often shows up on another. A failed authentication attempt might appear on several systems within a few seconds. Looking for those events means repeating the same searches until you've checked every machine.

Forwarding logs removes most of that work. Each server keeps writing logs locally, but it also sends another copy to a central rsyslog server. When you start investigating, that's normally the first system you open.

You'll use two services to make that happen. journald records the log messages. rsyslog forwards them using your Linux syslog configuration. The logs stay on the local machine, but another copy is already waiting on the central server.

How Journald and Rsyslog Work Together

journald records the logs on each Linux system. rsyslog moves those logs to the central server, while journalctl lets you check the local copy.

Component	Role in centralized logging
journald	Records log messages on the local Linux system.
journalctl	Reads and searches the logs stored by journald.
rsyslog	Forwards local log messages to the central rsyslog server.
Central rsyslog server	Receives logs from multiple Linux systems and stores them in one place.

Why Centralized Logging Matters

Centralized logging keeps another copy of your logs on a separate system, so they remain available even when the original server isn't.

Local logs work well until the server becomes part of the problem. A failed disk, an accidental deletion, or a compromised system can remove the records you were planning to review.

A central logging server changes that. Every Linux system still keeps its own logs, but it also forwards another copy across the network. If one machine becomes unavailable, the forwarded logs are still there.

The difference becomes obvious during an investigation. The same application error, failed login, or service failure can appear on several systems within a few minutes. Searching one central rsyslog server is usually faster than repeating the same search on every machine.

Long-term storage gets easier too. Production servers no longer have to keep months of historical logs because the central server is already collecting them. That's one reason centralized log management is commonly used for troubleshooting, compliance, and incident response.

Step 1: Verify Journald and Rsyslog Are Installed

journald and rsyslog both need to be running before logs can be forwarded to another system.

Start with journald.

systemctl status systemd-journald

The service should report:

Active: active (running)

That tells you the local journal is running.

rsyslog is next.

systemctl status rsyslog

You're looking for the same status.

Active: active (running)

An inactive service isn't running. A failed service tried to start but stopped because of an error. Both need to be fixed before log forwarding will work.

Step 2: Configure Persistent Journald Storage

Persistent journal storage keeps log messages after a system reboot.

A reboot can interrupt an investigation just as quickly as a deleted log file. If the journal only exists in memory, everything recorded before the restart disappears with it.

Creating /var/log/journal changes that.

sudo mkdir -p /var/log/journal

Restart journald after creating the directory.

sudo systemctl restart systemd-journald

From that point on, new journal entries are written to disk instead of temporary storage.

journalctl can confirm the change.

journalctl --disk-usage

You'll see how much space the journal is using. If the output reports disk usage, journald is writing persistent logs.

Step 3: Configure Journal Retention

Journal retention controls how long journald keeps logs and how much disk space they can use.

Persistent storage keeps logs after a reboot. Retention decides how much of that history stays available. Without limits, the journal keeps growing until it reaches the storage limits of the system.

The retention settings live in the journald configuration file.

sudo nano /etc/systemd/journald.conf

You'll find several options that control how the journal stores and removes log data.

Setting	What it changes
Storage=	Chooses whether the journal is stored in memory, on disk, or both.
Compress=	Compresses older journal files to reduce disk usage.
Seal=	Adds integrity protection so changes to journal files can be detected.
SystemMaxUse=	Limits how much disk space persistent journals can use.
RuntimeMaxUse=	Limits how much memory runtime journals can use.
MaxRetentionSec=	Removes journal files after they've reached the configured age.

A small server and a production server rarely need the same retention policy. A development system might only keep a few days of logs. A production server often keeps weeks or months, depending on available storage and internal requirements.

One example looks like this.

[Journal]
Storage=persistent
Compress=yes
Seal=yes
SystemMaxUse=2G
RuntimeMaxUse=200M
MaxRetentionSec=30day

Each setting changes a different part of how the journal grows over time. SystemMaxUse keeps the journal from filling the disk. MaxRetentionSec removes older logs after they reach the configured age. Compress reduces the space used by older journal files, while Seal helps detect whether those files have been modified. Together, these settings keep the journal large enough for troubleshooting without allowing it to consume all available storage.

Step 4: Configure Rsyslog to Receive Journald Messages

journald already has the logs. The next step is getting those logs to rsyslog.

Nothing leaves the server yet. Every log message is still local, even though persistent storage is enabled. Forwarding starts once journald begins passing its messages to rsyslog.

Open the journald configuration file.

sudo nano /etc/systemd/journald.conf

Find this setting.

ForwardToSyslog=yes

On many Linux distributions, rsyslog already receives messages from journald through its default configuration. If ForwardToSyslog is disabled and rsyslog isn't receiving journal entries, enable it by removing the leading # or adding the setting if it doesn't exist.

Restart both services after saving the file.

sudo systemctl restart systemd-journald
sudo systemctl restart rsyslog

From this point on, new journal entries are handed to rsyslog as they're created. The logs still exist on the local server, but rsyslog can now process and forward them to another system.

One quick check is enough before moving on.

systemctl status rsyslog

rsyslog should report active (running). The next step is giving it a server to forward those logs to.

Step 5: Configure a Central Rsyslog Server

A central rsyslog server receives log messages from every Linux system that forwards logs to it.

Open the main rsyslog configuration file:

sudo nano /etc/rsyslog.conf

Add the following lines to enable a TCP listener on port 514:

module(load="imtcp")
input(type="imtcp" port="514")

Before restarting rsyslog, check the configuration for syntax errors:

sudo rsyslogd -N1

A successful check should end with a message indicating that the configuration validation completed without errors.

Next, allow TCP port 514 through the firewall.

On Ubuntu or Debian systems using UFW:

sudo ufw allow 514/tcp

On RHEL-family systems using firewalld:

sudo firewall-cmd --permanent --add-port=514/tcp
sudo firewall-cmd --reload

Restart rsyslog:

sudo systemctl restart rsyslog

Confirm that the service is running:

sudo systemctl status rsyslog

Then verify that rsyslog is listening on TCP port 514:

sudo ss -lntp | grep ':514'

The output should show a listening socket on port 514.

By default, some Linux distributions write incoming remote messages to the same system log used for local events, while others use different destinations depending on the rsyslog configuration. For larger environments, many administrators create a dedicated directory such as /var/log/remote/ and store logs in separate folders for each hostname to simplify troubleshooting and log retention.

Step 6: Configure Linux Clients to Forward Logs

Every Linux client needs a forwarding rule before log messages can reach the central rsyslog server. This rule tells rsyslog where to send copies of locally generated log messages.

The server is ready to receive logs. The clients still need to know where those logs should go. That's done with a forwarding rule in the rsyslog configuration.

A basic forwarding rule looks like this.

*.* @@192.168.1.100:514

Replace 192.168.1.100 with the address of your rsyslog server.

The *.* selector forwards every facility and every priority. The double @@ sends log messages over TCP. A single @ sends them over UDP.

TCP is the better choice for most centralized logging deployments. It confirms messages are delivered before sending the next one. UDP sends messages without waiting for a response. It's faster, but dropped packets stay dropped.

Many production environments also encrypt remote logging with TLS. The forwarding rule stays the same. The rest of the Linux syslog configuration adds the certificates needed to secure the connection.

Restart rsyslog after saving the configuration.

sudo systemctl restart rsyslog

New log messages now have somewhere to go.

Step 7: Verify Logs Reach the Central Server

A test message confirms the entire centralized logging pipeline is working.

There's no reason to wait for a real event. Generate one instead.

logger "LinuxSecurity centralized logging test"

The message should appear in the local journal.

journalctl -n 10

Search for the test message if it's easier to spot.

journalctl | grep "LinuxSecurity centralized logging test"

The same message should also appear on the central rsyslog server.

On Debian and Ubuntu systems, check:

grep "LinuxSecurity centralized logging test" /var/log/syslog

On RHEL-family systems, check:

grep "LinuxSecurity centralized logging test" /var/log/messages

You can also search both common locations:

sudo grep -R "LinuxSecurity centralized logging test" \
  /var/log/syslog /var/log/messages 2>/dev/null

Log file locations vary by distribution and rsyslog configuration. If you configure a custom template for remote logs, search that directory instead.

Step 8: Secure Your Logging Infrastructure

A centralized logging server holds data from every system that forwards logs to it, so it needs the same level of protection as the systems it monitors.

Log forwarding moves copies of your logs across the network. Encrypting that traffic with TLS keeps log messages from being read or modified while they're in transit. That's especially important when remote logging crosses untrusted networks.

The logs themselves need protection too. Limit access to the rsyslog server, use restrictive file permissions, and avoid giving unnecessary users access to log data. The fewer people who can modify log files, the easier they are to trust during an investigation.

Some environments take another step and use immutable storage. Once the logs are written, they can't be changed without leaving evidence behind. That's useful when logs need to support compliance requirements or forensic investigations.

Many organizations also separate logging traffic from normal application traffic. A dedicated logging network reduces unnecessary exposure and keeps large volumes of log data away from production workloads.

The logging server should follow the same maintenance routine as any other Linux system. Rotate log files before they fill the disk, back up important log data, and test those backups regularly. A backup that has never been restored is only a backup on paper.

Step 9: Troubleshoot Common Logging Problems

Most centralized logging problems come down to a small number of configuration or connectivity issues.

A journal that disappears after every reboot usually points to non-persistent storage. Check that /var/log/journal exists and confirm the retention settings in journald.conf.

Logs that never reach the rsyslog server often trace back to the forwarding rule. Review the Linux syslog configuration, restart rsyslog, and confirm the service is still running.

Firewalls block more logging traffic than most configuration mistakes. If the client can generate logs but the server never receives them, verify the listening port is open on both systems.

Missing log entries usually mean looking at both ends of the pipeline. Check the local journal with journalctl first. If the event exists there but not on the central server, the problem happened after journald recorded the message.

Incorrect timestamps make investigations much harder. Systems that don't share the same time source rarely produce logs that line up correctly. Keeping every server synchronized with NTP avoids that problem.

Duplicate log entries usually mean the same message is being forwarded more than once. Review your rsyslog rules and look for overlapping forwarding configuration.

A full disk eventually stops log collection. Check available storage on both the client and the rsyslog server, then review your journal retention and log rotation settings before services start dropping messages.

Best Practices

A few small configuration choices make centralized logging much easier to manage over time.

• Keep persistent journald storage enabled.
• Forward logs from every Linux system instead of only critical servers.
• Encrypt remote logging with TLS whenever possible.
• Limit access to the rsyslog server and its log files.
• Monitor available disk space on both clients and the logging server.
• Rotate logs before storage becomes a problem.
• Test log forwarding after configuration changes.
• Keep every system synchronized with NTP.
• Review your syslog configuration after major operating system updates.

Conclusion

You now have a basic centralized logging pipeline: journald records events locally, rsyslog forwards them over TCP, and the central server stores another copy for investigation and retention.

Local logs remain useful for troubleshooting individual systems, while the central server gives you one place to compare events across your environment. Test forwarding after every configuration change, monitor available storage, and regularly confirm that incoming logs are being retained as expected.

Plain TCP forwarding is a good starting point for a private network. For a production deployment, the next step is to secure the connection with TLS and organize incoming logs by hostname.
